Description
TM029B is a corrugated conduit in LAGRA's Mainflex TM series, made from polyamide (PA6). The product is specified with a nominal diameter (NW) of 29 and supplied on rolls of 25 m per roll. The TM029B has a stated protection class of IP68 and a temperature range of -40 °C to 150 °C.Features
- Material: PA6 (polyamide)
- Corrugated cross-section as specified by the manufacturer
- Protection class: IP68
- Temperature range: -40 °C to 150 °C
- Delivery: 25 m per roll
- Halogen and cadmium-free material specification
- Stated resistance to media: alcohols, greases, mineral oils, and fuels
Technical context
As a PA6-based corrugated conduit, the manufacturer highlights TM029B's material properties and its resistance to a range of chemical media. The IP68 protection class indicates that the product is specified with a high level of ingress protection according to the manufacturer's instructions. The product's dimensions (inner and outer diameter) and delivery length are specified by the manufacturer and should be used directly for planning and procurement.Documentation
See datasheet from the manufacturerSpecifications
- Product name: TM029B
- Manufacturer: LAGRA
- Material: PA6
- Nominal diameter (NW): 29
- Inner diameter (ID): 29 mm
- Outer diameter (AD): 34.5 mm
- Length: 25 m per roll
- Temperature range: -40 °C to 150 °C
- Protection class: IP68
- Halogen and cadmium-free
- Resistant to: alcohols, greases, mineral oils, and fuels
The content is AI-generated – we reserve the right for errors.
Contact HIN for further product information.
