Fluke T6-1000 PRO Electrical Tester
The Fluke T6-1000 PRO is an electrical tester for working on installations and systems where you need to measure voltage, current, and check for continuity in a conductor. The special feature of the instrument is its open fork, allowing current to be measured without connecting a traditional clamp or test lead directly to the metal part of the conductor.
This makes it practical for troubleshooting motors, pumps, control panels, and other places where you quickly want an overview of what's happening in the circuit. You can read AC/DC voltage up to 1000 V, AC current up to 200 A, and resistance, and it can also be used for frequency measurement via the open fork. This provides a good working tool when troubleshooting or confirming that an installation is performing as expected.
Visual Continuity™ is a simple aid for continuity testing: the screen turns green when there is continuity. This is useful when the environment is noisy or when it's difficult to hear a regular signal. The HOLD function makes it easier to retain a measurement so it can be read at leisure, and the backlit LCD screen helps when working in dim light.
The T6-1000 PRO is relevant when you want to measure quickly and directly on conductors with ample space in the opening, and at the same time have an instrument that can be used in general electrical work with the safety categories associated with that type of task.
You can read more here:
See data sheet from the manufacturer
Specifications
- AC/DC voltage up to 1000 V
- AC current up to 200 A
- Resistance measurement from 1 Ω to 100 kΩ
- Frequency measurement from 45 Hz to 66 Hz via open fork
- FieldSense measurement through open fork
- Visual Continuity™ with green screen indication for continuity
- HOLD function
- Backlit LCD screen
- Fork opening: 17.8 mm
- For conductors up to AWG 4/0, approx. 120 mm²
- Safety category: IEC 61010 CAT IV 600 V and CAT III 1000 V
- Powered by 2 x AA batteries
