ESD Clipper t/print separation 1.5mm track

Product Overview

This manual depaneling tool, DP 15 N D from PIERGIACOM, is designed for separating printed circuit boards (depaneling). The DP 15 N D is the ESD version of model DP 15 N and is described by the manufacturer as a hand tool for fast and economical separation of PCBs with clean cut edges.

Technical Description

The core function of the tool is mechanical separation of PCBs using a blade of specified thickness. The following features and limits are specified by the manufacturer and apply to the DP 15 N D:

• Blade thickness: 1.5 mm
• Maximum PCB thickness: 1.6 mm
• Maximum cutting force: 3 kg
• Tool length: 147 mm
• Weight: 90 g
• Maximum allowable isthmus (tab) length during separation: 3 mm
• Minimum isthmus distance: 11 mm

Typical Applications

Used for separating printed circuit boards (depaneling) by manual cutting, where the specified limits for isthmus length (max. 3 mm) and minimum distance (11 mm) are met. The DP 15 N D is used in situations where an ESD version of the depaneling tool is required, as indicated by the manufacturer's model designation.

Documentation

Product information has been verified on the manufacturer's product page. See manufacturer's product page

Specifications

• Product name: DP 15 N D (ESD version of DP 15 N)
• Blade thickness: 1.5 mm
• Max. PCB thickness: 1.6 mm
• Max. cutting force: 3 kg
• Length: 147 mm
• Weight: 90 g
• Max. isthmus length: 3 mm
• Minimum isthmus distance: 11 mm

Source: Piergiacomi product page (product DP 15 N / DP 15 N D)
