Product Overview
This Wiha TorqueVario®-S ESD torque screwdriver (item no. 26866) is an adjustable torque screwdriver with a settable torque range of 0.5–2.0 Nm and a 4.0 mm hex socket. The tool is ESD-compliant according to IEC 61340-5-1, and its dissipative handle has a surface resistance in the range of 10^6 - 10^9 ohms. Torque achievement is signaled by both an audible and tactile click, and the release accuracy is stated as ±6% according to EN ISO 6789.
Features and Contents
- Adjustable torque range: 0.5–2.0 Nm
- 4.0 mm hex socket
- ESD-compliant: IEC 61340-5-1
- Dissipative handle, surface resistance 10^6 - 10^9 ohms
- Audible and tactile click at preset torque
- Release accuracy: ±6% (EN ISO 6789)
- Includes Torque-Setter adjustment tool and 1/4" bit holder
- Compatible with 4 mm Wiha Torque interchangeable blades (series 2859)
- Includes factory inspection protocol
- Product dimensions: 202 x 35 x 35 mm
Documentation
Technical details and an overview of torque tools are documented in the manufacturer's material. See manufacturer's datasheet
Typical Applications
The Wiha TorqueVario®-S ESD (26866) is used for precise tightening with a set torque within the range of 0.5–2.0 Nm and in situations where ESD protection is required. The tool's click function is used to confirm that the preset torque has been achieved.
Specifications
- Product: Wiha TorqueVario®-S ESD, item no. 26866
- Torque range: 0.5–2.0 Nm
- Socket: 4.0 mm hex
- ESD standard: IEC 61340-5-1
- Handle surface resistance: 10^6 - 10^9 ohms
- Release accuracy: ±6% (EN ISO 6789)
- Included accessories: Torque-Setter adjustment tool, 1/4" bit holder
- Compatibility: 4 mm Wiha Torque interchangeable blades (series 2859)
- Included documentation: factory inspection protocol
- Dimensions: 202 x 35 x 35 mm
