Introduction
This No-Clean flux product from STANNOL, AK-1, is a halogen-free, resin-free active flux developed for tinning cables and soldering on copper or copper-passivated surfaces. AK-1 is classified according to DIN EN 29454-1, Type 2.2.3.A (F-SW 23) and is described as leaving very low residues in the No-Clean category.Properties
- Halogen-free and resin-free formulation.
- Described as No-Clean with very low residues.
- Colourless liquid with a stated density of 0.806 g/cm3 at 20 °C.
- Stated thinner: Stannol VD-500.
- Shelf life: 2 years from date of manufacture when stored correctly in original sealed packaging.
Typical Applications
AK-1 is used for cable tinning and soldering on copper or copper-passivated surfaces. The product is primarily intended for immersion (dip/tank), but can also be applied by brush, drop, or dispenser. In the datasheet, the following soldering methods are explicitly mentioned as applicable for AK-1:- Dip/tank application (immersion)
- Brush, drop, or dispenser application
- Wave, induction, plate heating, or hand soldering
Documentation
For technical details and safety instructions, please refer to the manufacturer's technical data sheet. See data sheet from the manufacturerSpecifications
- Product name: AK-1
- Manufacturer: STANNOL
- Description: Halogen-free, active, resin-free No-Clean flux (DIN EN 29454-1, Type 2.2.3.A / F-SW 23)
- Application: Cable tinning and soldering on copper/copper-passivated surfaces
- Application methods: dip/tank, brush, drop, dispenser; suitable for wave soldering, induction, plate heating, and hand soldering
- Colour: colourless
- Density (20 °C): 0.806 g/cm3
- Thinner: Stannol VD-500
- Shelf life: 2 years from date of manufacture when stored correctly in original sealed packaging
The content is generated using AI – we reserve the right to make errors.
Contact HIN for further information about the product.
