GEDORE VDE 30 15
GEDORE VDE 30 15 is an insulated socket for 3/8" hand tools, for working on electrical installations requiring VDE safety. It is used for standard hexagonal nuts and bolts with a 15 mm wrench size, and it is made for tasks where both correct fit and electrical protection are desired.
The socket is made of GEDORE vanadium steel 31CrV3, making it suitable for a professional toolbox where tools must withstand daily use. At the same time, it is insulated up to 1000 V according to EN 60900 / IEC 60900. This means it is intended for working on live parts when the task is performed by trained electricians and with the correct VDE-approved tools.
The two-layer Check-Tool insulation makes it easy to see if the insulation is intact. When the yellow inner color becomes visible, it is a clear sign that the tool should be taken out of use. The socket also has an insulation projection of 16–18 mm, which is part of the construction around the insulated part.
In practice, it is a spare part or a single tool for tasks where a 3/8" ratchet or other 3/8" accessories are used, and a 15 mm socket is needed, without compromising electrical safety.
Typical applications
- Work on electrical systems with VDE requirements
- Assembly and service where 15 mm hex is used
- Use with 3/8" hand tools
Specifications
- Manufacturer: GEDORE
- MPN: 2946467
- EAN: 4010886947494
- Product: VDE 30 15
- Type: VDE-insulated hexagon socket insert
- Square drive: 3/8" (10.0 mm)
- Wrench size: 15 mm
- Material: GEDORE vanadium steel 31CrV3
- Insulation: up to 1000 V according to EN 60900 / IEC 60900
- Insulation: two-ply Check-Tool insulation
- Insulation projection: 16–18 mm
- Insertion diameter Ø1: 25.0 mm
- Insertion diameter Ø2: 23.0 mm
- Insertion length: 46.0 mm
- Overall width: 25 mm
- Weight: 0.05 kg
See datasheet from the manufacturer
