Product Overview
The 100NHG02B is an Eaton Bussmann NH low voltage fuse in size NH02, intended for AC systems. Rated at 100 A and 500 V AC, the 100NHG02B features a ceramic square body, blade contacts, and blade-end connections. The product has metal "live" gripping lugs and a combined fuse-blown indicator. citeturn0search0turn0search5
Design and Function
The 100NHG02B fuse has an NH02 design with a ceramic square body and blade contacts. It is specified as gL/gG (utilisation category) and has a breaking capacity of 120 kA (interrupt/breaking rating). The connection is blade-end, and the product is stated as suitable for use with the BVL50 microswitch. The specified standards and compliance include IEC 60269-1/2, DIN 43620, and CE marking. citeturn0search0turn0search5
Typical Applications
- Specified by the manufacturer for use in industrial applications. citeturn0search0
- The manufacturer notes applications in the energy sector, including solar and wind-related installations. citeturn0search0
Key Features
- Rated current: 100 A.
- Rated voltage: 500 V AC.
- Utilisation category: gL/gG (cable and equipment protection).
- Breaking capacity / interrupt rating: 120 kA.
- Ceramic square body with blade contacts and blade-end connection.
- Metal live gripping lugs and combined fuse indicator.
- Stated compatible with microswitch BVL50.
Specifications
- Manufacturer/Series: Eaton Bussmann (BUSSMANN). citeturn0search0
- Type/Part number: 100NHG02B.
- Fuse size: NH02.
- Rated current: 100 A.
- Rated voltage AC: 500 V AC.
- Utilisation category: gL/gG.
- Breaking capacity: 120 kA (interrupt/breaking rating).
- Construction/Material: Ceramic square body, blade contacts.
- Connection: Blade-end connection.
- Fitted with: Metal live gripping lugs.
- Fuse indicator: Combination fuse status indicator.
- Compliances: IEC 60269-1/2, DIN 43620, CE.
- Suitable for: Microswitch BVL50.
