SIB-TEC CEM M40 Cable Gland (Brass)
This text describes the SIB-TEC CEM M40 cable gland from SIB (manufacturer reference C5240200). The product is a brass cable gland designed for sealing and securing cables at penetrations with ISO-threaded fittings.Function and Construction
- Product Name: SIB-TEC CEM M40 (reference number C5240200).
- Materials specified in manufacturer documentation: body and nut in nickel-plated brass, insert in PA6, metallic insert (chain/gripping element) in stainless steel.
- Seals and Gaskets: packing sealing rings in neoprene 65 ShA and O-rings in nitrile 70 ShA.
- Thread Type: ISO-threaded specified in the documentation.
Typical Applications
This cable gland is used for sealing and clamping cables in penetrations where an ISO-threaded mounting and mechanical retention are required. The description is based on the manufacturer's technical information for SIB-TEC CEM M40 (C5240200).Documentation
See the manufacturer's technical documentation for detailed dimensions and material descriptions:
See datasheet from the manufacturerSpecifications
- Manufacturer: SIB
- Product Reference: C5240200 (SIB-TEC CEM M40)
- Thread: ISO (M40 specified in the documentation)
- Clamping Range: 15 / 27 mm (min / max)
- H: 42 mm
- E: 8 mm
- L: 41 mm
- Ø C: 27.5 mm
- Ø P: 28 mm
- Weight: 125 g
- Protection Rating: IP 68
- Temperature Range (application): -40 / +100 °C (listed as permanent operating temperature in the documentation)
- Materials: body and cap in nickel-plated brass; insert in PA6; metallic insert in stainless steel; seals in neoprene 65 ShA; O-rings in nitrile 70 ShA.
The content is generated using AI – we reserve the right for errors.
Contact HIN for further information about the product.
