Product Overview
The Kugelanschlussbolzen 63-0103-003 from HORSTMANN is a ball connection bolt specified on the manufacturer's product page for Phasenfestpunkte (phase connection points). The product is listed with a diameter of 25 mm and an M16 internal thread, as well as a stated rated short-circuit current (bemessungswert Ir) for 1 second of 29.6 kA. The Kugelanschlussbolzen is designed to function as a phase connection point and for fastening current-carrying rails.Materials and Construction
- Material (straight/knurled bolts): E-Cu, tinned (verzinnt) — as specified by the manufacturer.
- Material (angled/abgewinkelte bolts): CuCr, tinned (verzinnt) — as specified by the manufacturer.
Documentation
References and data are based on HORSTMANN's product information for Phasenfestpunkte. Source: HORSTMANN product pageTypical Applications
- Used as a phasesanschluss (phase connection) in electrical systems, according to the manufacturer's product text.
- Used for busbar fastening screws (stromschienenverschraubung), according to the manufacturer's product text.
Technical Description
The Kugelanschlussbolzen 63-0103-003 is listed in Horstmann's table of Phasenfestpunkte with indications of mechanical connection dimensions and a noted short-circuit capacity. The spherical contact surface is described by the manufacturer as designed to compensate for movements and ensure uniform force and current distribution at phase connections. Horstmann also emphasizes installation requirements: correct assembly and maintenance of the prescribed tightening torque for full functionality and vibration security.Specifications
- Product name: Kugelanschlussbolzen 63-0103-003
- Manufacturer: HORSTMANN
- Diameter: 25 mm
- Thread: M16 (internal thread)
- Rated short-circuit current Ir (1 s): 29.6 kA
- Material (straight bolts): E-Cu, tinned
- Material (angled bolts): CuCr, tinned
- Application: usable as a phase connection and for busbar fastening
