STAUBLI 08.0710
STAUBLI 08.0710 is a single-pole, uninsulated round connector of the F/M18 type. It belongs to Stäubli’s range of connections for power transmission, where a robust and pluggable electrical connection is required in an industrial setup.
In practice, it is used as part of an assembly where the connection must be able to be disconnected without altering the entire installation. This type of connection is typically found where live parts are involved, and where space, installation, and operational reliability must be balanced. The fact that it is uninsulated means that it is integrated into a design where the mounting and installation conditions themselves must be considered.
Stäubli specifies dimensions A = 30 mm, B = 19 mm, and C = 4.2 mm. DIN 6798 is stated as the applicable standard in the catalog. This information is useful when the part needs to fit into an existing construction or with other components in the same series.
See datasheet from the manufacturer
Specifications
- Manufacturer: STAUBLI
- MPN: 08.0710
- Type: F/M18
- Product series: Round Connectors 1-pole uninsulated
- Design: single-pole, uninsulated round connector
- Dimension A: 30 mm
- Dimension B: 19 mm
- Dimension C: 4.2 mm
- Applicable standard: DIN 6798
The content has been generated using AI - we reserve the right for errors.
Contact HIN for further information about the product.
