STAUBLI FLEXI-2V 0.75
The STAUBLI FLEXI-2V 0.75 is a highly flexible cable for tasks requiring a slender conductor with secure insulation and good electrical capacity. It has a cross-section of 0.75 mm² and reinforced, double PVC insulation, which makes it suitable for installations where high safety standards are required.
The cable is constructed with 196 fine strands, which is why it can be bent and handled so easily in practice. This is particularly noticeable in panel building, test setups, and other technical environments where cables often need to be routed in confined spaces or laid neatly and clearly.
It is rated for AC 1000 V and DC 1500 V with a current rating of 15 A. The temperature range is from -10 °C to +70 °C. The outer diameter is 3.5 mm, and the conductor diameter is 1.25 mm, resulting in a relatively compact cable with high flexibility.
Typical Applications
The cable is typically used where electrical and electronic construction is involved, and where flexibility and secure insulation are important. It is relevant in professional contexts where a conductor that is easy to handle is desired and that also meets the specified approvals such as UR, CE, UKCA, and EAC.
Specifications
- Manufacturer: STAUBLI
- MPN: 60.7028-10021
- Product name: FLEXI-2V 0.75
- Cross-section: 0.75 mm²
- Conductor construction: 196 x 0.07 mm
- Conductor diameter: 1.25 mm
- Outer diameter: 3.5 mm
- Insulation thickness: 1.1 mm
- Insulation: reinforced double PVC insulation
- Rated voltage: AC 1000 V / DC 1500 V
- Rated current: 15 A
- Temperature range: -10 °C to +70 °C
- Approvals: UR, CE, UKCA, EAC
- See datasheet from the manufacturer
