Product Overview
The FLEXI-E 0.10 is a flexible, insulated stranded conductor (wire) with a nominal cross-sectional area of 0.10 mm² from STAUBLI (item number 60.7001-10022). The product is described in the manufacturer's datasheet as a "highly flexible basic insulated stranded wire" and states both electrical and mechanical parameters for the wire.
Technical Details
- Conductor cross-section: 0.10 mm²
- Strand design: 26 × 0.07 mm
- Conductor diameter: 0.4 mm
- Overall cable diameter: 1.0 mm
- Insulation material: PVC
- Insulation thickness: 0.3 mm
- Rated values: 150 V AC, 2 A
- Temperature range: −10 °C to +70 °C
- Lead weight: 1.8 kg/km
- Approvals stated in datasheet: CE, UKCA, EAC
Documentation
The manufacturer's technical information and specifications are published in STAUBLI's datasheet. For further verification of the stated values, please refer to the manufacturer's datasheet documentation.
Sources
See datasheet from the manufacturer
Specifications
- Product name: FLEXI-E 0.10
- Manufacturer: STAUBLI
- Item number: 60.7001-10022
- Conductor cross-section: 0.10 mm²
- Rated values: 150 V AC, 2 A
- Insulation material: PVC
- Temperature range: −10 °C ... +70 °C
- Strand design: 26 × 0.07 mm
- Conductor diameter: 0.4 mm
- Cable diameter: 1.0 mm
- Insulation thickness: 0.3 mm
- Lead weight: 1.8 kg/km
- Stated approvals: CE, UKCA, EAC
- Datasheet date on manufacturer's site: 02.2025
