Product Overview
This soldering tip from WELLER, Weller PT B9 (item no. 4PTB9-1), is a chisel tip designed for use with the Weller Magnastat system. The Weller PT B9 is specified as "Soldering Tip, Chisel 480°C, Ø 2.4 mm" and comes in a single pack. The working temperature for this tip is 480°C, as indicated by the manufacturer's technical data.Function and Compatibility
- Compatibility: Used with the Weller Magnastat system, where the operating temperature is determined by the temperature-sensitive properties of the tip.
- Temperature Control: The Magnastat system adjusts power supply using a ferro-magnetic sensor in the tip; this achieves switching between high power for soldering and reduced power during idle by changing the temperature-sensitive tip.
Documentation
Refer to the manufacturer's technical information for details and data confirmation: See datasheet from manufacturer.Typical Applications
Used with the Weller Magnastat system to achieve the specified working temperature by switching to a temperature-sensitive chisel tip. This description is directly based on the manufacturer's information about the function and compatibility of PT Soldering Tips.Specifications
- Item No: 4PTB9-1
- Product Name: Weller PT B9
- Product Family: PT Soldering Tips
- Tip Type: Chisel
- Tip diameter (stated in product text): Ø 2.4 mm
- Technical diameter (stated in technical data): 6.9 mm
- Length: 33 mm
- Temperature: 480°C (depends on tool / Magnastat system)
- Quantity per pack: 1
- UPC: 4003019432370
- Compatibility: Weller Magnastat system (temperature selection via temperature-sensitive soldering tip)
The content is generated using AI – we reserve the right for errors.
Contact HIN for further information about the product.
