CELLTECH LS14500
The CELLTECH LS14500 is a primary lithium-thionyl chloride battery in AA size. It is used when a small 3.6 V energy source is needed, but the battery does not need to be recharged. In practice, it is a cell for equipment that must be able to run stably over a long period without frequent replacement.
The capacity is stated as 2.6 Ah when measured at 2 mA, +20 °C and with a 2.0 V cut-off. This means that the battery is intended for low power consumption in many applications. At the same time, the maximum recommended continuous current is 50 mA, while the pulse capability is stated up to 250 mA. This makes it relevant for equipment where consumption is usually low, but where higher loads can occur for short periods.
At +20 °C, the open-circuit voltage is stated as 3.67 V, and the nominal voltage at 0.2 mA is 3.6 V. This is worth knowing when the battery is used in equipment that is sensitive to voltage levels and operating time.
Typical applications
- Utility meters
- IoT devices
- Tracking systems
- Alarm and security equipment
- Connected sensors
- Medical equipment
Specifications
- Manufacturer: CELLTECH
- MPN: LS14500
- Type: Primary lithium-thionyl chloride cell
- Size: AA
- Nominal voltage: 3.6 V
- Open-circuit voltage at +20 °C: 3.67 V
- Nominal voltage at 0.2 mA and +20 °C: 3.6 V
- Nominal capacity: 2.6 Ah
- Capacity measurement conditions: 2 mA, +20 °C, 2.0 V cut-off
- Maximum recommended continuous current: 50 mA
- Pulse capability: up to 250 mA
