Product Overview
The ME3-50 is a hexagonal crimping die from CEMBRE's ME-50 family, designed for 50 kN crimping tools. The product is identified as ME3-50 (part number 2676020) and is specified for a conductor cross-section of 16 mm² with impression marking A3. The die is manufactured from specially hardened steel and has a blued surface treatment.
What the product does
The ME3-50 is used as an insert in compatible 50 kN crimping heads to perform mechanical crimping of cable lugs/connectors for the specified conductor cross-section. The shape is hexagonal, which reflects the profile formed in the crimp.
Technical reference and documentation
- Dimensions: 38x24x7 mm
- Material: specially hardened steel with blued surface
See datasheet from the manufacturer
Typical applications
The ME3-50 is intended for use in 50 kN crimping heads and is, among other things, specified for use in tool types such as the HT51 series. Usage involves inserting the connector/cable lug into the die before closing, in accordance with the manufacturer's instructions.
Specifications
- Manufacturer: CEMBRE
- Manufacturer part number: 2676020
- Product name: ME3-50
- Product category: Hexagonal crimping die (ME-50 family)
- Specified for use with: 50 kN crimping tools / 50 kN crimping heads
- Specified conductor cross-section: 16 mm²
- Impression marking: A3
- Material: Specially hardened steel with blued surface treatment
- Dimensions: 38x24x7 mm
- Compatibility: Recommended for 50 kN crimping heads as used on the HT51 series
