Product Overview
The Eaton Bussmann series low voltage D fuse, 35D33, is a low voltage D fuse designed for circuit protection at up to 500 V AC. The product is listed on the manufacturer's page as a D33 time-delay fuse with a rated current of 35 A and an interrupting capacity of 50 kA.What the product is and does
This Eaton Bussmann 35D33 fuse is a DIII "bottle"-shaped insert with a ceramic body and non-indicating design. It is specified as a Class C gL/gG fuse (cable and equipment protection) with a time-lag / time-delay characteristic, as stated directly on the manufacturer's product page. The product's primary function is to interrupt current in overcurrent situations within the specified electrical limits.- Model: FUSE-D3 35A T GL/GG 500VAC E33 (specified as model code).
- Rated current and voltage: 35 A, 500 V AC.
- Interrupting capacity / interrupt rating: 50 kA (50 kAIC).
Installation and Compatibility
Product information indicates compatibility with E33/DIII fuse bases as well as specific base types: TFD33 (screw fixing), SFRD33, and TFRD33 (DIN rail mounting). The fuse is specified as non-indicating and comes in packs of 25 according to manufacturer data.Typical Applications
According to the manufacturer's product page, the application is stated as "For domestic and general industrial applications". The product's designated application category gL/gG indicates use for cable and equipment protection in the specified application types.Specifications
- Product name: Eaton Bussmann series low voltage D fuse.
- Catalog number: 35D33.
- Model code: FUSE-D3 35A T GL/GG 500VAC E33.
- Manufacturer: BUSSMANN (Eaton Bussmann).
- Rated current: 35 A.
- Voltage rating: 500 V AC.
- Interrupting capacity / Interrupt rating: 50 kA (50 kAIC).
- Classification: Class C gL/gG.
- Fuse type: D33 - Time delay / Time-lag.
- Fuse size / construction: DIII (D3), "bottle" shape.
- Material: White ceramic body (specified by the manufacturer).
- Color: Black (specified by the manufacturer).
- Fuse indicator: Non-indicating.
- Compatible bases: E33/DIII, TFD33, SFRD33, TFRD33.
- Dimensions (L×H×W): 50 mm × 27 mm × 27 mm.
- Weight: 51 g.
- Certifications & compliance: VDE; IEC 60269; DIN EN 60269-3; DIN EN 60269-1; DIN VDE 0636-301; CE Marked; GoST-R; RoHS Compliant.
- Pack size: 25 pcs.
- Application stated by manufacturer: For domestic and general industrial applications.
