Product Overview
The Insulated SoftFinish® electric slimFix Torx screwdriver, size T20 is an insulated TORX T20 screwdriver from WIHA (item number 36538). The product combines a SoftFinish® ergonomic handle with Wiha slimTECHNOLOGY, where the insulation is integrated into the blade itself. This combination allows access to low-lying screws while the screwdriver is designed for working on live components.
What it is and what it does
The Insulated SoftFinish® electric slimFix Torx screwdriver, size T20 is a manual, insulated TORX screwdriver designed for hand fastening screws. The integrated insulation and routine single testing in accordance with IEC 60900 make the tool suitable for working near live parts up to 1,000 V AC. Wiha slimTECHNOLOGY allows for a blade up to 33% slimmer, so the tool can reach deep-seated screws and spring elements where a standard blade cannot penetrate.
Design and relevant features
- SoftFinish® ergonomic handle, designed for transmitting hand force.
- Integrated insulation in the blade (slimTECHNOLOGY) for a slimmer profile and access to deep-lying screws.
- Visible blade of 100 mm and overall length of 211 mm.
- Handle diameter 30 mm and weight 55 g.
- Inspected and manufactured in accordance with IEC 60900.
Typical applications
The documented application of the product is work in the vicinity of live parts up to 1,000 V AC, as well as manual fastening of screws where access to low-lying screw heads is required.
Specifications
- Manufacturer: WIHA
- Item number: 36538
- Product name: Insulated SoftFinish® electric slimFix Torx screwdriver, size T20
- TORX size: T20
- Visible blade: 100 mm
- Overall length: 211 mm
- Handle diameter: 30 mm
- Weight: 55 g
- Material: Chrome-vanadium-molybdenum steel, black finish
- Insulation: Integrated insulation (Wiha slimTECHNOLOGY)
- Standard/test: Manufactured in accordance with IEC 60900; VDE and GS tested
- Application: For working in the area of live parts up to 1,000 V AC
