HIKMICRO E1L Handheld Thermal Camera
The HIKMICRO E1L is a compact handheld thermal camera for troubleshooting, used to visualize temperature differences rather than merely measuring a single point. The camera displays an infrared image with 160 × 120 resolution, and the built-in laser pointer helps indicate the center point on the physical object.
This makes it easier to locate heat development, cold spots, and other deviations in installations and equipment. The display is a 2.4" LCD with 240 × 320 resolution, allowing the image to be read directly in hand. With a temperature measurement range from -20 °C to 550 °C, it can be used in many technical contexts where quick visual temperature control is needed.
The camera is built for portability. It weighs approximately 350g, is IP54 rated, and has passed drop tests from 2 meters. At the same time, the battery life is stated to be approximately 8 hours, allowing it to be used throughout a workday without constant charging.
For measurements close to the object, the minimum focus distance is 0.15 m. This is especially practical when working on components or installations where you get very close. The stated NETD of < 40 mK means that the camera is sensitive to small temperature differences, and the image refresh rate is 25 Hz.
Typical applications
- HVAC inspection
- Electrical inspection
- Automotive inspection
- Mechanical inspection
View datasheet from manufacturer
Specifications
- Manufacturer: HIKMICRO
- MPN: 308200100
- IR Resolution: 160 × 120 (19,200 pixels)
- Object Temperature Range: -20 °C to 550 °C
- NETD: < 40 mK
- Frame Rate: 25 Hz
- Display: 2.4" LCD, 240 × 320
- Laser Pointer: Yes
- Minimum Focus Distance: 0.15 m
- IP Rating: IP54
- Drop Test: 2 m
- Weight: approx. 350 g
- Battery Life: approx. 8 hours
- EAN/GTIN: Not specified
