Product Overview
This leakage current clamp from BENNING is a TRUE RMS leakage current clamp meter with multimeter functions. The BENNING CM 9-1 measures leakage and differential currents and provides measurements of AC current, voltage, resistance, and continuity.Features
- TRUE RMS leakage current clamp (BENNING CM 9-1).
- Resolution 1 µA in 6 mA measurement range.
- Measures leakage currents and differential currents.
- AC current measurement up to 60 A.
- Multimeter functions: voltage measurements up to 600 V, resistance up to 600 kΩ, and continuity test.
- Clamp opening: 23 mm.
- Category classification: CAT IV 300 V and CAT III 600 V.
- Supplied with carrying case, test leads, and batteries (BENNING item number 044682).
Typical Applications
- Used for measuring leakage currents and differential currents, including small current measurements with 1 µA resolution in the 6 mA range.
- Used for AC current measurements up to 60 A as well as for voltage measurements up to 600 V.
- Used for resistance measurements up to 600 kΩ and for continuity testing.
Documentation
Further product information can be found with the manufacturer.
Source: manufacturer's product page
Specifications
- Product name: BENNING CM 9-1.
- Item number: 044682.
- Function: TRUE RMS leakage current clamp meter.
- Resolution: 1 µA in 6 mA measurement range.
- Current measurement: up to 60 A AC.
- Voltage measurement: up to 600 V.
- Resistance: up to 600 kΩ.
- Continuity test: yes.
- Clamp opening: 23 mm.
- Safety categories: CAT IV 300 V, CAT III 600 V.
- Included: carrying case, test leads, and batteries.
