Fluke 719Pro-300G Electric Pressure Calibrator
The Fluke 719Pro-300G is a handheld pressure calibration instrument with an electric pump built into the unit itself. This means that pressure can be generated and adjusted with one hand, which is practical when working on site or during service tasks where equipment, hoses, and connections often need to be held simultaneously.
The instrument is used for calibrating pressure transmitters, pressure switches, and pressure gauges. At the same time, it also functions as a loop calibrator because it can source, simulate, and measure mA signals. This makes it relevant when both pressure and electrical process signals need to be checked in the same workflow.
The pressure range goes up to 300 psi / 20 bar, making it suitable when working with relatively high pressures. The fine resolution and specified accuracy make it suitable for tasks where precise adjustment and stable readings are required. In practice, this means that it not only displays the pressure but also allows for more controlled trimming and verification of measurement equipment.
The included accessories support daily use: test leads with alligator clips, fluid trap, hose kit, and carrying case. This makes the instrument ready for fieldwork without the need to assemble everything separately.
You can read more here:
See data sheet from the manufacturer
Specifications
- Electric pressure calibrator with integrated electric pump
- Pressure range: -12 to 300 psi (-0.8 to 20 bar)
- Pressure measurement resolution: 0.01 psi
- Pressure accuracy: ±0.025% of full scale for 6 months
- Pressure accuracy: ±0.035% of full scale for 1 year
- Can source, simulate, and measure mA
- Supports 0–24 mA loop functions
- Supplied with test leads with alligator clips
- Supplied with fluid trap
- Supplied with carrying case
- Supplied with accessory hose kit
- Supplied with traceable certificate of calibration
The content is generated using AI - we reserve the right for errors.
Contact HIN for further information about the product.
